ProMinent gamma/ X Supplementary Operating Instructions

Index Sub Name Type Description Categ.* Attr
Bit#1: SoftwareR‐
eset
Bit#2: Parameter
problem
Bit#3: Memory
resource problem
Bit#4: Application
failure
Bit#5: Failure in
control software
Bit#6: Failure of
operation system
software
Bit#7: Failure in
communication soft‐
ware
Bit#8 to 31
Reserved
04h Software failure
codes 2
U32 MANDA RO
05h Mechanics failure
codes 1
U32 MANDA RO
06h Mechanics failure
codes 2
U32 MANDA RO
07h Electrics failure
codes 1
U32 MANDA RO
08h Electrics failure
codes 2
U32 MANDA RO
0Dh Operation failure
codes 1
U32 MANDA RO
0Eh Operation failure
codes 2
U32 MANDA RO
0Fh Operation failure
codes 3
U32 MANDA RO
10h Auxiliary device
failure codes 1
U32 MANDA RO
11h Auxiliary device
failure codes 2
U32 MANDA RO
12h Auxiliary device
failure codes 3
U32 MANDA RO
Index Sub Name Type Description Categ.* Attr
6001h 00h
HighestSubInde
x
U32 Warning codes MANDA RO
01h Hardware warning
codes 1
U32 MANDA RO
Supplementary Operating Instructions CANopen
30

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
