ProMinent gamma/ X Supplementary Operating Instructions

Index S Name Type Description Objects Attr
5D00h 0
PCO_HighestSubI
ndex
U8 RO
1 Name1 String Pump name RO
2 Name2 String RO
3 Name3 String RO
4 Name4 String RO
5 Name5 String RO
6 Name6 String RO
7 Name7 String RO
8 Name8 String RO
5D01h 0
PCO_HighestSubI
ndex
U8 RO
1 Location1 String Pump installation
location
RO
2 Location 2 String RO
3 Location 3 String RO
4 Location 4 String RO
5 Location 5 String RO
6 Location 6 String RO
7 Location 7 String RO
8 Location 8 String RO
5042h 1 Identification_LED U16 0 - off
> 0 - Set identifica‐
tion time (LED
yellow + red flash for
duration)
1 - equivalent to
approx. 10 ms
SDO RW
5FEE 0 CANopenStackRevi‐
sion
UINT32 ProMinent CAN‐
open-Stack-Revision
RO
2.7.1.4 Device profile area 0x6000-0x9FFF
Index Sub Name Type Description Categ.* Attr
6000h 00h
HighestSubInde
x
U32 Failure codes MANDA RO
01h Hardware failure
codes 1
U32 MANDA RO
02h Hardware failure
codes 2
U32 MANDA RO
03h Software failure
codes 1
U32 Bit#0: Software‐
Fault
MANDA RO
Supplementary Operating Instructions CANopen
29

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
