ProMinent gamma/ X Supplementary Operating Instructions

Index S Name Type Description Objects Attr
5145h 1 Diaphragm U8 Diaphragm error sig‐
nalling
RW
5146h 1 AnalogueCurveError U8 Error signalling for
analogue curve
RW
Index S Name Type Description Objects Attr
5147h 1 Relay1-Type U16 Relay-Type (0-
warning,1-error, 2-
warn.+error, 3-
warn.+error+stop, 4-
stop, 5- clock)
RW
5148h 1 Relay2-Type U16 Relay-Type (0-
warning,1-error, 2-
warn.+error, 3-
warn.+error+stop, 4-
stop, 5- clock)
RW
5149h 1 Relay1-Polarity U16 Relay polarity (0-
attracting(NO), 1-
falling off (NC))
RW
514Ah 1 Relay2-Polarity U16 Relay polarity (0-
attracting(NO), 1-
falling off (NC))
RW
514Bh 1 Analogue-Out-Range U16 Analogue output
range (0: 0-20mA,1:
4-20mA)
RW
514Ch 1 Analogue-Out-Func‐
tion
U16 Analogue-Function
(0:strokes/min, 1: cur‐
rent metering
capacity, 2: Capacity
at 20mA)
RW
514Dh 1 Analog-Out-Capacity U16 Adjustable capacity at
20mA
RW
Index S Name Type Description Objects Attr
514Eh 1 NomFreqStrokesper‐
Hour
U16 Nominal metering
capacity in strokes/
hour
RW
514Fh 1 CalibReset U16 Calibration reset RW
5150h 1 BatchQuantity U32 Set metering quantity RW
5151h 1 DeviceName U16 Device name ro
5152h 1 DeviceLocation U16 Device installation
location
ro
5153h 1 Betriebsdruck U16 Pressure stages (0: 4
bar, 1: 7 bar; 2: 10
bar, 4: 12 bar)
RW
Supplementary Operating Instructions CANopen
28

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
