ProMinent gamma/ X Supplementary Operating Instructions

Index S Name Type Description Objects Attr
5131h 1 Calibration counter U8 Calibration stroke
counter
PDO Rw
5132h 1 Calibration value U16 Calibration value
(total quantity)
PDO Rw
Index S Name Type Description Objects Attr
5133h 1 Viscosity U8 Viscosity level ro
5134h 1 Stroke length U16 Stroke length PDO ro
5135h 1 Stroke counter U32 Stroke counter PDO rO
5136h 1 Quantity counter U32 Volume counter PDO rO
5137h 1 Clear counters U8 Clear counter WO
5138h 1 Strokes left U32 Remaining strokes PDO RO
Index S Name Type Description Objects Attr
5139h 1 Quantity left U32 Remaining quantity PDO RO
513Ah 1 User code U16 User password PDO WO
513Bh 1 Language index U8 Language index RW
513Ch 1 Analogue external U16 Analogue value at
external input
PDO RO
513Dh 1 Quantity per stroke U16 Metering quantity
per stroke at 100%
stroke length
PDO RO
513Eh 1 NomFreq_Litreper‐
Hour
U16 Requested metering
frequency in litres/
hour
PDO RO
Index S Name Type Description Objects Attr
513Fh 1 Metering control U8 Metering monitoring RW
5140h 1 Metering-Control-
Pulses
U16 Defective strokes for
metering monitoring
RW
5141h 1 Dosing-Control-by-
Aux
U8 Metering monitoring
in aux mode
RW
5142h 1 Metering-Control-
Errorsignal
U8 Metering monitoring
error signalling
RW
5143h 1 Access level U8 Access protection
level (0-none, 1-
menu blocked, 2-
continuous display
and menu blocked)
RW
5144h 1 Unit U8 Pump unit ( 0-litre, 1-
gallon)
RW
Supplementary Operating Instructions CANopen
27

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
