ProMinent gamma/ X Supplementary Operating Instructions

Index S Name Type Description Objects Attr
5114h 1 hw_version_fc U32 Hardware version of
FC
RO
5115h 1 sw_version_pfc U32 Software version of
PFCU
RO
5116h 1 hw_version_pfc U32 Hardware version of
PFC
RO
5118h 1 serial_number U32 Serial number of
SxCn
RO
Index S Name Type Description Objects Attr
5120h 1 Nominal frequency U16 Setpoint frequency PDO Rw
5121h 1 Actual frequency U16 Setpoint frequency PDO RO
5122h 1 Nominal mode U8 Setpoint operating
mode:
PDO Rw
5123h 1 Actual mode U8 Actual operating
mode
PDO RO
5124h 1 Analogue mode U8 Analogue mode: PDO Rw
Index S Name Type Description Objects Attr
5125h 1 Analogue curve U8 Curve type for ana‐
logue
ro
5126h 1 Curve-IP1 U16 Current at curve point
1
rW
5127h 1 Curve-FP1 U16 Stroke rate at curve
point 1
rW
5128h 1 Curve-IP2 U16 Current at curve point
2
rW
5129h 1 Curve-FP2 U16 Stroke rate at curve
point 2
rW
512Ah 1 Auxiliary U16 Auxiliary frequency ro
512Bh 1 Metering mode U8 Metering mode
(metering profile)
Rw
Index S Name Type Description Objects Attr
512Ch 1 Batch memory U8 Saving function for
batch metering:
PDO ro
512Dh 1 Batch factor U16 Batch_factor PDO ro
512Eh 1 Contact memory U8 Saving function for
contact metering:
PDO ro
512Fh 1 Contact factor U16 Contact factor PDO ro
5130h 1 Pressure control U8 Pressure gauge Rw
Supplementary Operating Instructions CANopen
26

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
