ProMinent gamma/ X Supplementary Operating Instructions

Index S Name Type Description Objects Attr
3 Name3 String RO
4 Name4 String RO
5 Name5 String RO
6 Name6 String RO
7 Name7 String RO
8 Name8 String RO
5D01h 0 PCO_High‐
estSubIndex
U8 RO
1 Location1 String Pump instal‐
lation location
RO
2 Location 2 String RO
3 Location 3 String RO
4 Location 4 String RO
5 Location 5 String RO
6 Location 6 String RO
7 Location 7 String RO
8 Location 8 String RO
5042h 1 Identifica‐
tion_LED
U16 0- off SDO rw
>0 Set identi‐
fication time
(LED yellow
+red flash for
duration)
1 equivalent
to approx. 10
ms
5FEE 0 CANopen‐
StackRevi‐
sion
UINT32 ProMinent
CANopen-
Stack-Revi‐
sion
RO
2.7.1.3 Device specific area 0x51000-0x5FFF
Tab. 8: HMI area 0x5100 – 0x5FFF
Index S Name Type Description Objects Attr
5111h 1 sw_version_ctrl U32 Software version of
control
RO
5112h 1 hw_version_ctrl U32 Hardware version of
control
ro
5113h 1 sw_version_fu U32 Software version of
FC
RO
Supplementary Operating Instructions CANopen
25

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
