ProMinent gamma/ X Supplementary Operating Instructions

Start byte Length Data type Name Explanation
11 2 Unsigned16 Remaining strokes The number of
strokes still to be
performed in batch
metering in pro‐
gress
13 1 Unsigned8 Fault Flags for fault
sources - see
"Fault" table
14 1 Unsigned8 Warning Flags for warning
sources - see
"Warning" table
15 2 Integer16 MaxFreq Maximum fre‐
quency in
strokes/min that
can be metered
17 4 Integer32 Number of strokes Number of strokes
performed since the
last reset
21 4 Floating LpH Metering volume in
litres (gallons) per
stroke
25 4 Floating Quantity Metered volume in
litres (gallons) since
the last reset
Tab. 41: Status
Item Name Status "0" Status "1"
2
0
Operating mode continuous Charge=1;
Contact=2;
Analogue=3
2
1
Operating mode - -
2
2
Fault No fault No fault present
2
3
Warning No warning Warning present
2
4
Priming No priming Priming
2
5
Auxiliary frequency Aux. Freq. off Pump metering with aux.
Freq.
2
6
Pause No pause Pause externally con‐
nected
2
7
Stop Pump is running Pump stopped
2
8
Option FlowControl Not present Present
2
9
FlowControl Metering monitoring
deactivated
Metering monitoring acti‐
vated
2
10
- - -
2
11
Dividing factor 1:1 1:100
2
12
BatchMemory Deactivated Activated
2
13
Measuring unit Litres Gallons
Supplementary Operating Instructions PROFIBUS
®
82

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
