Front Panel LEDs
QGD-1600P
No. Component No. Component
1 Host port speed LED 8 Fan LED
2 Host port activity LED 9 Power LED
3 Combo port speed LED 10 Switch status LED
4 Combo port activity LED 11 Gigabit 802.3at PoE+ port speed LED
5 QTS status LED 12 Gigabit 802.3at PoE+ port activity LED
6 Drive 1 LED 13 Gigabit 802.3bt PoE++ port speed LED
7 Drive 2 LED 14 Gigabit 802.3bt PoE++ port activity LED
QGD Rackmount Switch User Guide
Product Overview 11
