Setting Description
Port Status Go to Port Management > Port Status to view the following port status
information:
• Port number
• Port link status
• Port state
• Port speed
• Flow control
• Maximum frame size
Port Statistics a. Go to Port Management > Port Statistics to view the statistics of the
network ports.
b.
Click to change the viewing option to List View.
Power Consumption a. Go to PoE.
The Power Consumption page opens.
b. Select the port.
The current power consumption of the port is displayed.
System Management
The System section provides access to device conguration options.
Conguring Connection Settings
1. Log in to QSS, or open QuNetSwitch in QTS.
2. Go to System Management > Settings > IP .
3. Congure the connection settings.
Setting Description
Obtain IP & DNS automatically Obtain the IP & DNS information automatically from the DHCP server.
Tip
Click to refresh the IP & DNS information.
Set the IP & DNS manually Specify the IP & DNS manually.
4. Click Apply.
QSS or QuNetSwitch updates the connection settings.
Updating the Switch Password
1. Log in to QSS, or open QuNetSwitch in QTS.
2. Go to System Management > System Settings > Password .
QGD Rackmount Switch User Guide
Switch Management 71
