5. Congure the settings.
Setting Description
PoE Mode Controls the PoE operating mode for the port
Priority Controls the priority of each port
If multiple ports share the same priority, the port with the lower
number is given priority.
Power Consumption Displays the amount of power currently consumed by the powered
device
6. Click Apply.
QSS or QuNetSwitch saves the PoE settings.
Conguring a PoE Schedule
1. Log in to QSS, or open QuNetSwitch in QTS.
2. Go to Conguration > PoE .
3. Go to PoE Schedule.
4. Identify a port.
5.
Click
Scheduling is enabled for the port.
6.
Click
The PoE Schedule Conguration window opens.
7. Congure the schedule.
a. Optional: Select additional ports.
Selected ports will also be included in the schedule.
b. Select port operating hours.
c. Optional: Select Activate schedule now.
8. Click Save.
The PoE Schedule Conguration window closes.
9. Click Apply.
QSS or QuNetSwitch saves the schedule.
Adding a VLAN
A virtual LAN (VLAN) groups multiple network devices together and limits their broadcast domain. Members
of a VLAN are isolated and network trac is only sent between group members
Each VLAN is assigned a specic VLAN identication number. The VLAN screen displays information about
existing VLANs and provides access to VLAN conguration options.
1. Log in to QSS, or open QuNetSwitch in QTS.
2. Go to Conguration > VLAN .
QGD Rackmount Switch User Guide
Switch Management 63
