1. Press Enter or Select.
The panel displays the device name and QTS version.
2. Press and hold Enter for two seconds.
The panel displays Main Menu 1. TCP/IP.
3. Press and hold Enter.
The panel displays the IP address of the rst network adapter.
4. Press Select repeatedly until the panel displays Enter Network Settings.
5. Press and hold Enter.
The panel displays the congurable network settings.
6. Press Select and then Enter to congure the settings.
Button Usage
Enter • Display a conguration screen.
• Move to the next item on a conguration screen.
Select • Move to the next item on a menu.
• Modify a value on a conguration screen.
Viewing Drive Information
The LCD panel can display the temperature and capacity of each drive installed in the device.
1. Press Enter or Select.
The panel displays the device name and QTS version.
2. Press and hold Enter for two seconds.
The panel displays Main Menu 1. TCP/IP.
3. Press Enter repeatedly until the panel displays Main Menu 2. Physical disk.
4. Press and hold Enter.
The panel displays the temperature and capacity of the drive in slot 1.
5. Press and hold Select.
Repeat this step as necessary.
The panel displays the temperature and capacity of the next drive.
Viewing System Information
The LCD panel can display the CPU temperature, system temperature, and system fan speed.
1. Press Enter or Select.
The panel displays the device name and QTS version.
2. Press and hold Enter for two seconds.
The panel displays Main Menu 1. TCP/IP.
3. Press Enter repeatedly until the panel displays Main Menu 4. System.
4. Press and hold Enter.
The panel displays the CPU and system temperature.
QGD Rackmount Switch User Guide
Basic Operations 55
