Condensed Operating Instructions (continued)
Recalling Setups/Preprogrammed Test Conditions
1. Press the TEST NUMBER key to sequence up through the test setups, those with no
program stored will show the message “No Test Programmed”. Continue to press the key
repeatedly to select any setup desired (user test 1-25, or sequence S1-S9). Typical display
below shows setup #1 programmed for AC Hipot at 500 volts, high current limit of 15 mA
and test time of 7 seconds. Note the message “Idle” in the upper right display, this area
always indicates the instrument status. (Pressing the up/down arrow key will also
sequence through the test setups, up or down)
2. Once the desired test # has been selected (remains displayed) it is possible to view all test
parameters by pressing the left/right arrow keys as follows:
Press arrow for
VIEW mode
Press arrow to
view next parameter
Press arrow to
view next parameter
Press to continue VIEW or
Press to reverse direction
To Next Page
