5. To set Arc Limit (AC or DC Current only):
Press up/down arrow keys to increase or decrease the limit setting between Off and
0.5mA to 15.00mA (for AC Current) and between Off and 0.5mA to 15mA (for DC Current).
The arc limit can be limited (see below) to less than that indicated above depending on
the Hi Limit setting and is checked only during the programmed ramp and test times.
Arc Level AC: 0.5mA - 15mA in 0.5mA increments
Arc Level DC: 0.5mA - 15mA in 0.5mA increments
Arc Limit does not apply to GC Only or IR mode (Guardian 2530)
Press right arrow key to move to the next parameter ( left arrow for previous
parameter) or PROGRAM key to exit program mode.
6. To set Ramp Time:
Press up/down arrow keys to increase or decrease the ramp time between Off and
0.1 to 999.9sec. The test voltage increases linearly during the programmed ramp time. The
standard Hi/Lo Limits are not checked during this ramp time, for current checking
during ramp time refer to Hi Lim Ramp (step 7) and Lo Lim Ramp(step 8).
Press right arrow key to move to the next parameter ( left arrow for previous
parameter) or PROGRAM key to exit program mode.
7. To set Hi Lim Ramp (AC or DC Current only,not available with Ramp Time set Off):
Press up/down arrow keys to increase or decrease the limit setting between Off and
0.001mA and 15.000mA (for AC Current) or 0.0001mA and 7.500mA (for DC Current) or
0.01MΩ and 2000000MΩ (for Insulation Resistance). This Hi Lim Ramp limit is checked
only during the programmed ramp time.
Press right arrow key to move to the next parameter ( left arrow for previous
parameter) or PROGRAM key to exit program mode.
