QuadTech Guardian 2500 Series User Manual

Operation/Programming Page 63 of 63
10. Ground Fault Stop
This selection determines the status of ground fault detection. When On is selected the unit
monitors the ground return current, and if found to be different from the output current the
instrument is shut down. This is a safety feature, intended to make sure that the difference in
current is not in a path through the operator. When set to Off fault detection is not monitored.
When set to Off – DUT Grounded, the Return input is at chassis ground rather than virtual
ground.
Press the UTILITY key and right arrow key to select Enhanced Features.
If Enhanced Features is set for On, press right arrow key to select Ground Fault Stop.
If Enhanced Features is set for Off, press up/down arrow key to select On and press
right arrow key to select Ground Fault Stop.
Press up/down arrow keys to select Ground Fault Stop, Off, On or Off – DUT
Grounded.
Press the UTILITY key to exit, or move to other Utility functions with the right arrow key.
Perform Calibration Util
Cal Date: 1/12/1999
Ground Fault Stop Util
Off
Ground Fault Stop Util
On
Ground Fault Stop Util
Off – DUT Grounded
