QuadTech Guardian 2500 Series - Programming Sequence Tests; Sequence Test #1

Page 46 of 46 Operation/Programming
2.3 Programming Sequence (Tests S1 - S9)
A sequence test consists of 1, 2 or 3 tests in sequence. Selected tests can consist of any of the
user defined tests (1 - 25), or a calculated test, which can be a calculated value for Total, Real or
Imaginary current based on the AC Hipot measurement conditions defined in the first step of the
sequence. A calculated test is not a valid entry for step 1 of a sequence, a calculated test can
only be called for in step 2 and/or 3 of the sequence where the test called for in step 1 must
be an AC Hipot test.
Table of Programmable Parameters
For Setting Up Sequence Testing (S1 – S9)
Test #
Programmable Tests for
the Sequence
1
none, 1 thru 25, skip
2
none, 1 thru 25, skip, calc
3
none, 1 thru 25, skip, calc
Programmable
Parameters for
calc
Programmable
Hi/lo Limits for
Total, Real, or
Imag Current
Programmable
Range
AC Total Current
AC Real Current
AC Imag Current
Hi Lim
Lo Lim
0.000 – 15.000mA
0.000 – 15.000mA
1. To Program Sequence Test #1
Press the TEST NUMBER key to select test setup for programming (sequence S1 - S9).
Continue to press the key repeatedly to select the setup desired, for example: S1 as shown
below.
Press PROGRAM key, to allow entry of a test number in step number 1. Also note that the
“Idle” message now indicates “Program.” Press up/down arrow keys to select the first
test in the sequence as none, skip or 1 – 25 (Calculate can not be selected on the first step).
S1 Idle
Tests: none
