Page 68 of 68 Operation/Programming
2.6 Error Messages
Operator Help messages
All tests are disabled, program test
Arc limit must be less, than max gain current
Arc limit changed to be, less than max current
Arrow, test, utility, and start keys are valid
DEVICE UNDER TEST, FAILED TEST
DUT resistance too low Programmed voltage cannot be maintained across
DUT, it may be necessary to increase RAMP time
or DWELL time
ERROR IN CALCULATION, Press STOP to clear
First step cannot, be a calc test
GC resistance too high Ground continuity circuit is too resistive to allow
the test current of 100 mA to be passed through it
(>> 10 ohms), probably due to a faulty connection.
Ground fault detected, Press STOP to clear
GROUND CONTINUITY, LIMIT TOO HIGH
Handler start ignored, Invalid test number
High limit changed to be, greater than low limit
High limit can not be, greater than max current
High limit changed to, correspond to meas param
High ramp changed to, correspond to meas param
High changed to be, greater than low ramp
Interlock Open Advance handler interlock is enabled and open
INVALID RAMP TIME
INVALID DWELL TIME
INVALID DISCHARGE TIME
NO MEASUREMENT, PARAMETER SPECIFIED
INVALID RAMP LIMIT
INVALID HIGH LIMIT
Limits changed to be, valid for setup
Low limit must be less, than the high limit
Low limit changed to be, less than the high limit
Low ramp changed to be, less than the high ramp
Low limit changed to, correspond to meas param
Low ramp changed to, correspond to meas param
Measured parameter must, be set to program
MEASUREMENT TIMED OUT, Press STOP to clear
