Condensed Operating Instructions (continued)
Connection Using Test Leads (Part # 2000-02)
Connection Using Corded Product Adapter (Part # 2000-13)
Black Lead
Small White Lead
G.C. RETURN HV OUT
DUT
Guardian 2510/20/30
Case
Large White Lead
White (Banana to clip)
Black (lug)
Black (banana)
White
G.C. RETURN HV OUT
DUT
Guardian 2510/20/30
Case
BNC to banana plug adapter
