Page 56 of 56 Operation/Programming
2.4.9 Enhanced Features
The Guardian 2500 allows operator selection of enhanced features. The available enhanced
features include:
Test Low Limit Clear All Tests
Delay Time Tests To View
Continue Voltage On Fail Perform Calibration
Continue Steps On Fail Ground Fault Stop
Stop Test On Pass Arc Pulse Width
Step And Increment Adaptive DC Ramp
Autoranging
Press the UTILITY key and right arrow key to select Enhanced Features.
Press up/down arrow keys to select the display of these features On or Off, as
programmed. Selecting Off only prevents the enhanced features from being displayed on
the Utility menu. It does not change the operation of any of these enhanced features.
1. Test Low Limit
This selection determines when the low limit is checked. If Continuous is selected the low limit
is checked throughout the complete measurement time, including ramp time. If End of Test is
selected the low limit is checked only at the end of the measurement time.
Press the UTILITY key and right arrow key to select Enhanced Features
If Enhanced Features is set for On, press right arrow key to select Test Low Limit.
If Enhanced Features is set for Off, press up/down arrow key to select On and press
right arrow key to select Test Low Limit.
Press up/down arrow keys to select Test Low Limit for Continuous or End of Test.
