Qualstar Q40 - Front Panel

511026 Rev. 07-01-19
15
2.3 Front Panel
1
Left Magazine Emergency Release
Access Hole
2
Left Magazine Access Handle
3
Power Button
Base Module Only
4
Unit Identification LED, Blue
Base Module Only
5
Ready LED, Green
Base Module Only
6
Clean LED, Amber
Base Module Only
7
Attention LED, Amber
Base Module Only
8
Error LED, Amber
Base Module Only
9
USB Port
Base Module Only
10
Operator Control Panel (OCP) Display
Base Module Only
11
Back/Return Button
Base Module Only
12
Navigation Button - Left
Base Module Only
13
Navigation Button – Up
Base Module Only
14
Navigation Button – Down
Base Module Only
15
Navigation Button – Right
Base Module Only
16
Enter Button
Base Module Only
17
Mailslot/Right Magazine Access Handle
18
Right Magazine Emergency Release
Access Hole
