5.2 Magazine Buttons
Each magazine has a button that provides an easy way to unlock a magazine.
E
ach magazine can be configured to have a portion designated as a mailslot. To unlock the mailslot,
press the magazine button for less than 3 seconds.
To unlock the entire magazine, press the magazine button for more than 3 seconds.
The user will need to pull out the magazine, as the magazine does not eject.
A
fter a magazine has been open and closed, a library inventory will be performed. The LED on the button
provides an indicator of the current state of that magazine.
T
able 13 : Magazine States
Magazine State LED state Description
Closed Steady ON mailslot is enabled
Closed Slow Flash Magazine unlock is in progress
Closed Fast Flash Magazine is unlocked
Closed OFF mailslot is not enabled
Opened
OFF Magazine is opened
NOTE
1. If a magazine unlock is in process, no other magazines or mailslots can be
unlocked.
2. If an unlocked magazine is not opened within 30 seconds, the magazine will
be re-locked automatically.
