5.4.1.5 show spanning-tree summary
This command displays spanning tree settings and parameters for the switch. The following details are
displayed on execution of the command.
Syntax
show spanning-tree summary
Default Setting
None
Command Mode
Privileged Exec
Display Message
Spanning Tree Adminmode: Enabled or disabled.
Spanning Tree Forward BPDU: Enabled or disabled
Spanning Tree Version: Version of 802.1 currently supported (IEEE 802.1s, IEEE 802.1w, or IEEE
802.1d) based upon the Force Protocol Version parameter.
BPDU Guard Mode:Enabled or disabled.
BPDU Filter Mode: Enabled or disabled.
BPDU Uplinkfast Mode: Enabled or disabled.
Configuration Name: TConfigured name.
Configuration Revision Level: Configured value.
Configuration Digest Key: Calculated value.
Configuration Format Selector: Configured value.
MST Instances: List of all multiple spanning tree instances configured on the switch.
