Communications Protocol CubiScan 110-T Command Set
CubiScan 110-T 70
Command
(s)
Command
(s)
Command
(s)
Ack
(A)
Nack
(N)
Weight
(M000000.00)–
(M999999.99)
Comma
(,)
WeightStatus
(00)‐(99)
Comma
(,)
WeightUnits
(lb)or(kg)
Comma
(,)
CheckSum
‐Hex
(0000)‐(FFFF)
EndBytes
<ETX><CR><LF>
EndBytes
<ETX><CR><LF>
EndBytes
<ETX><CR><LF>
Length
5
Length
27
Length
6
Read/WriteValueTableDefinition
Number VariableName Type
Total
Length
Mantissa
Length
100‐
T
110‐
T
150‐
T
0000 MetricDimensions Boolean 1 0 x x x
0001 MetricWeight Boolean 1 0 x x x
0002 InternationalFactor Boolean 1 0 x x x
0003 EthernetDHCP Boolean 1 0 x x x
0004 UseEthernet Boolean 1 0 x x x
0005 UseLCD Boolean 1 0 x x x
0006 UseUltrasonicTransducers Boolean 1 0 x x x
0007 UseScale Boolean 1 0 x x x
0008 UseLanguage Boolean 1 0 x x x
0009 ScaleCalibrationWeight‐lb Float 5 2 x x x
0010 ScaleCalibrationWeight‐kg Float 5 2 x x x
0011 HeightCalibrationoffset Float 4 2   
0012 TouchscreenCalibrationX1 Float 9 6 x x x
0013 TouchscreenCalibrationX2 Float 9 6 x x x
0014 TouchscreenCalibrationX3 Float 9 6 x x x
0015 TouchscreenCalibrationY1 Float 9 6 x x x
0016 TouchscreenCalibrationY2 Float 9 6 x x x
0017 TouchscreenCalibrationY3 Float 9 6 x x x
0018
FirmwareVersion‐Main
Controller Float 5 3 x x x
