Communications Protocol CubiScan 110-T Command Set
CubiScan 110-T 71
0019 FPGAVersion Float 4 2
0020 Ring1Version Float 4 2
0021 Ring2Version Float 4 2
0022 Ring3Version Float 4 2
0023 SensorLength1DBW Float 4 1 x x x
0024 SensorWidthDBW Float 4 1 x x x
0025 SensorHeightDBW Float 4 1 x x x
0026 SensorLength1CPI Float 4 0 x x x
0027 SensorWidthCPI Float 4 0 x x x
0028 SensorHeightCPI Float 4 0 x x x
0029 SensorLength1Blanking Float 4 2 x x x
0030 SensorWidthBlanking Float 4 2 x x x
0031 SensorHeightBlanking Float 4 2 x x x
0032 SensorLength1Gain Float 4 1 x x x
0033 SensorWidthGain Float 4 1 x x x
0034 SensorHeightGain Float 4 1 x x x
0035 SensorLength1Pulse Float 2 0 x x x
0036 SensorWidthPulse Float 2 0 x x x
0037 SensorHeightPulse Float 2 0 x x x
0038 SensorLength1Delay Float 3 0 x x x
0039 SensorWidthDelay Float 3 0 x x x
Read/WriteValueTableDefinition
Number VariableName Type
Total
Length
Mantissa
Length
100‐
T
110‐
T
150‐
T
0040 SensorHeightDelay Float 3 0 x x x
0041 ScaleLDW Float 7 0 x x x
0042 ScaleLWT Float 7 0 x x x
0043 ScaleMsrTestMinimum0.00 Float 6 3 x x x
0044 ScaleMsrTestMaximum0.00 Float 6 3 x x x
0045 ScaleMsrTestAverage0.00 Float 6 3 x x x
0046
ScaleMsrTestMinimum25.00
‐Center Float 6 3 x x x
0047
ScaleMsrTestMaximum25.00
‐Center Float 6 3 x x x
0048
ScaleMsrTestAverage25.00‐
Center Float 6 3 x x x
0049
ScaleMsrTestMinimum50.00
‐Center Float 6 3 x x x
0050
ScaleMsrTestMaximum50.00
‐Center Float 6 3 x x x
