ESP-LX Modular Controller 9
Programming Checklist
To program the ESP-LX Modular controller for the first time, we
recommend that you complete the following steps in order. For
your convenience, a check-off box (
) is provided for each step.
Fill out Programming Chart ........................................ Page 10
Clear program information......................................... Page 12
Set language (optional).............................................. Page 40
Set date. ................................................................... Page 15
Set time . .................................................................. Page 16
For each program:
A B C D
Select program
(A, B, C, or D-drip). ................... Page 17
Set watering start times. ............ Page 18
Select days to water .................. Page 19
Set valve run time(s).................. Page 24
Confirm program ....................... Page 54
Set seasonal adjust % (optional). Page 25
Set valve delay (optional) ........... Page 33
Set watering delays (optional).................................... Page 30
Set special valve features (optional)
Cycle+Soak™...................................................Page 35
Master valve or pump start relay.........................Page 37
Sensor override .................................................Page 38
Back up programs (optional). .....................................Page 41
Set controller to automatic operation...........................Page 48
