Rain Bird ESP-LX User Manual

68 ESP-LX Modular Controller
Choose Location
Choose a location that:
 Is easily accessible
 Allows for comfortable viewing
 Has a flat wall surface
 Is near a 120 V or 230/240 V AC power source, depending on
model
 Is safe from potential vandalism
 Is outside the range of operating sprinklers
NOTE: This controller must be installed in
compliance with local electrical codes.

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
