ESP-LX Modular Controller 21
 Turn the dial to the next day of the week. Repeat steps 2
through 4 until you have set each day of the week on or off.
Odd/Odd31/Even Cycle
To set an Odd, Odd31, or Even cycle:
 Turn the dial to “ADVANCED CYCLES.”
 The display shows the currently selected program and its
current watering day cycle If the program you want is not
displayed, use the program select switch to change it. See page
17 for instructions.

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
