50 ESP-LX Modular Controller
Manual Watering
You can use the controller to manually operate a single valve,
several valves, or an entire program.
Start Valve
Selecting One or More Valves
 Turn the dial to “MANUAL WATERING.”
 The Manual Watering menu appears.
 Press “1” on the Manual Watering menu.
 The display shows Valve 1 and the run time set in the currently
selected program (or “0:00”). The valve number flashes.
 To select a different valve, press “+” or “–” until the valve
number you want appears.
 Press “Next.”

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
