26 ESP-LX Modular Controller
Individual Program
 Turn the dial to “SEASONAL ADJUST %.”
 The Seasonal Adjust menu appears.
 Press “1” on the Seasonal Adjust menu.
 The display shows the currently selected program and its
current seasonal adjustment percentage. The percentage
numbers flash. If the program you want is not displayed, use
the program select switch to change it. See page 17 for
instructions.
 Press “+” or “–” to set the percentage from 0 – 300 percent.
NOTE: Setting the percentage to “0” will prevent the
program from watering.
 To set the percentage for another program, use the program
select switch to change the program. Then repeat steps 2
through 6.

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
