Rain Bird ESP-LX User Manual

60 ESP-LX Modular Controller
 The Confirm Programs menu appears.
 Press “3” from the Confirm Programs menu.
 The display shows the first valve in the system, along with the
total amount of actual watering that will occur in each program
each day the program is scheduled to run.
 Press “+” or “–“ to change the valve number.
 Press “Back” to return to the Confirm Programs menu.
Test All Valves
The controller’s built-in test program will run each valve that has a
non-zero watering time assigned to it. When you run the test
program, the controller operates each valve in numerical sequence,
from lowest to highest. You can use this program to check out the
operation of all the sprinklers in the system.
 Turn the dial to “TEST ALL VALVES/CHECK SYSTEM.”

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
