Rain Bird ESP-LX User Manual

ESP-LX Modular Controller 67
INSTALLING THE
CONTROLLER
This section explains how to mount the ESP-LX Modular controller
on the wall and connect the wiring.
NOTE: This controller must be installed in
compliance with local electrical codes..
Installation Checklist
To install the ESP-LX Modular controller, we recommend you
complete the following steps in order. For your convenience, a
check-off box has been provided for each step.
 Check the box contents. ..............................................Page 67
 Choose a location. .......................................................Page 68
 Gather installation tools. .............................................Page 69
 Mount the controller. ...................................................Page 70
 Install module(s). ........................................................Page 72
 Connect field wiring. ...................................................Page 73
 Connect source power. ................................................Page 75
 Complete the installation. ............................................Page 78
Check Box Contents
ESP-LX Modular Controller
Mounting Hardware (5 screws,
5 plastic wall anchors)
Keys
ESP-LX Modular Installation,
Programming, & Operation
Guide
Mounting Template

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
