ESP-LX Modular Controller 39
 The Valve Settings menu appears.
 Press “4” on the Valve Settings menu.
 The display shows Valve 1 and its current setting for Sensor
Override, either On or Off. The setting flashes.
 To select a different valve, press “+” or “–” until the valve
number you want appears.
 Depending on how this valve is currently set, either “On” or
“Off” flashes. To allow this valve to operate when a sensor is
active, press “On.” To remove the sensor override from this
valve, press “Off.” The sensor override setting affects the
valve in all programs to which it is assigned.
 To select another valve, press “+” or “–” until the valve
number you want appears. Then repeat steps 6 and 7.

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
