Rain Bird ESP-LX User Manual

ESP-LX Modular Controller 53
 The display shows the currently selected program and “Manual
Watering/Start Program.” If the program you want is not
displayed, use the program select switch to change it. See page
17 for instructions.
 Press “Run” to manually start the program. “Watering”
appears in the display.
While the Program Is Running
 While the program is running manually and the dial is set to
“AUTO,” the display shows the program and valve currently
watering and the time left to water.
 You can press“+” or “–” to add or subtract run time from the
valve that is currently running.
 To advance to the next valve in the program sequence, press
“Adv Valve.” Go to step 1.
 To cancel the manual operation of the program, turn the dial to
“OFF” for three seconds. Then turn the dial back to “AUTO.”

Rain Bird ESP-LX Specifications

General

Enclosure rating	NEMA 3R
Sensor input	Yes
Type	Modular
Enclosure	Indoor/Outdoor
Display	LCD
Programs	4
Master Valve/Pump Start	Yes
Power Source	120V AC
Power supply	Included
Battery backup	Yes (for memory retention)
Cycle and soak	Yes
Mounting	Wall mount
