- 17 - V08 en, SCC
Main contactor
(K1)
Noise lter (Z1)
Solenoid Y2
control
SC Pump
(M4)
SCC - Parts location
SSR (V1-)
Control nozzle and
Thermocouple B2
CleanJet Pump (M6)
Drain valve
(M7 and S12)
Tripple Solenoid valve
Y1 Green Filling SG
Y3
Brown Moistening
Y4 Orange Care
CDS sensor
Loud speaker T2
