Rational CombiMaster Plus CMP User Manual

V08 en, SCC - 40 -
ONLY remove the SD card from the pcb, when the pcb must be replaced!
The SD card shall NOT be connected to any Windows based reader or Computer! Doing so will damage
the data structure on the SD card and your unit will no longer function!
The SD acts as the back up memory for all unit specic and customer data in case the main PCB must be
changed.
The SD card is unit specic and shall NOT be transferred from one unit to another!
Service part pcb’s are sent without SD card. Should you need to replace an original pcb by a service part pcb,
remove the SD card from the old pcb and insert it into the new pcb. The unit will not function if the SD card is not
inserted.
This SD card is specially formatted and congured for use in the SCC unit.
You can not replace it by a locally purchased SD card.
1 PCB New - No SD card inserted Unit will not function
2 PCB new - Original SD card
(standard service call)
Upload icon key is shown, When pressing the
icon for 10 seconds, data are copied from SD
card to pcb
3 PCB old - SD card is not inserted Unit is functioning, order new SD card from
Rational and insert (ref #4)
4 PCB old - new empty SD card
(42.00.128)
Data are copied automatically from pcb to SD
card.
5 PCB new - SD card from other
unit
(only in case of emergency, e.g
from unit from shown room,
when no SD card is available as a
service part)
Upload icon key is shown, When pressing
respective key for 10 seconds, data are copied
from SD card to pcb
6 a) SD card original - PCB from
other unit
(only in case of emergency, when
no PCB is available as a service
part)
b) PCB old - SD card from other
unit
Not needed as old PCB is work-
ing without SD card. Order new
SD card (42.00.128; ref #4)
Upload icon and download icon keys are shown,
Display: Please select for recovery:
PCB was replaced (a)
SD card was replaced (b)
When pressing respective key for 10 seconds,
data are copied from pcb to SD card or vice
versa. Note: Serial number will be copied too.
NOTE: There is no need to use a SD card from another unit as the original PCB will function even with-
out SD card. If needed order new SD (42.00.128) card and insert when available.
Service 17:
In case of Service 17 the main unit data are lost. Send the unit serial number to Rational. You will recieve a mail
containing recovery data or separate SD card. Unpack zip le onto empty white USB stick.
Upload data like soware update or insert new SD card. Aer recovery a Self test must be started.
On gas units ue gas analysis must be done aer nishing self test.
SD card - Changing PCB, new SD card
