- 19 - V08 en, SCC
Steam generator
ll box
High limit thermostats F3 / F4
Pressure sensor P1
Humidity valve Y5
Power supply pcb LED
A7/A8
Main pcb A2
Motor and inverter
Main contactor K1
SSR and cooling plate
SC pump M4
Cooling fan
Control transformer T1
Power supply door
Hand shower
Care pump M12
Cleanjet pump M6
Drain valve
CDS sensor
Quadruple solenoid
El. noise lter Z1
Loud speaker
Door contact
Air lter
Water connection
Drain connection
Level electrode S2
SCC_XS - Parts location
