Rational CombiMaster Plus CMP User Manual

V08 en, SCC - 76 -
+
CM_P - Diagnostic - dP
Description
connec-
tion
Temperature
display
Time display
Soware Version
Soware
Version: C - 1 -
Soware
Version: 07-01
B1 thermocouple
cabinet
actual value max value
Reset by pressing 5
seconds:
del will be displayed
B2 thermocouple
quenching
actual value max value
B3 thermocouple
core probe
actual value max value
B4 thermocouple
humidity
actual value max value
B5 thermocouple
steam generator
actual value max value
PCB temperature actual value max value
S2 level electrode S2: 0 - 1 Y1: 1 - 0
S3 door contact S3: 1 - 0
0 = open
1 = closed
Steam heating
0 = o; 50; 100
act. Temp. B5 0-50-100
Hot air heating
0 = o; 50; 100
act. Temp. B1 0-50-100
rpm fan motor
table unit / oor unit top
BUS set rpm actual rpm
rpm fan motor
oor unit bottom
BUS set rpm actual rpm only 201/202
Voltage signal P1 Oset actual value
humidity in %
clima valve
actual value 0 oder 1
calibration value
fan speed 1
Calibration values are all dierent depending on speed and
direction.
Press core temperature key; select dry, wet and combi with
temperature dial; keep pressed and select motor and direction
with timer dial.
calibration value
fan speed 2
calibration value
fan speed 3
calibration value
fan speed 4
SC Automatic
Steam SSR
time since last
SC automatic
in min.
Set time for SC pump in Min
Unit size / energy 61 - 202 ELE - GAS
ame current steam x.x µA ELE - GAS
ame current hot air
table unit / oor unit top
HL top
x.x µA
x.x µA
ame current hot air
oor unit bottom
HL bottom
x.x µA
HL top
x.x µA
Installation height
(boiling point)
HL bottom
x.x µA
Installation height
(P1 cold)
m Electric and Gas
