V08 en, SCC - 50 -
Fan motor SCC_XS 60
Dierences of fan motor for unit 6x 2/3
The motor 87.01.374 is used in all units size 60.
Electrical connection and control are identical with the Motor for
units 61-202.
The motor (87.01.375) and inverter (87.01.376) can be separated
by loosing 3 screws on the inverter.
The inverter parts can be ordered separately under part number
87.01.376
100 - 250VBus LED
