V08 en, SCC - 72 -
Heating/Motor Status Values
Steam 50% 0 or 1 B5 = X°C Start
Steam 100% 0 or 1 B5 = X°C Start
Hot air 50% 0 or 1 B1 = X°C Start
Hot air 100% 0 or 1 B1 = X°C Start
Fan Motor top Speed 1R Actual Speed X rpm Start
Fan Motor top Speed 1L Actual Speed X rpm Start
Fan Motor top Speed 3R Actual Speed X rpm Start
Fan Motor top Speed 3L Actual Speed X rpm Start
Fan Motor bottom Speed 1R Actual Speed X rpm Start
Fan Motor bottom Speed 1L Actual Speed X rpm Start
Fan Motor bottom Speed 3R Actual Speed X rpm Start
Fan Motor bottom Speed 3L Actual Speed X rpm Start
Water/CleanJet Status Values
Solenoid valve lling Y1 0 or 1 Level electrode S2: water or low water Start
SC Pump M4 0 or 1 Level electrode S2: water or low water Start
Solenoid valve quenching Y2 0 or 1 B2 = X°C Start
Solenoid valve moistening Y3 0 or 1 Start
Care valve Y4 + Pump M12 0 or 1 Level electrode S2: water or low water Start
Cleanjet Pump M6 0 or 1 Start
Drain valve motor M7 direction 1 0 or 1 End switch S12: 0 or 1 Start
Drain valve motor M7 direction 2 0 or 1 End switch S12: 0 or 2 Start
Components 1+2 Status
Loudspeaker T2 0 or 1 Start
Interior light 0 or 1 Start
Display test Start
Ultravent 0 or 1 Start
Energy optimising Start
Clima valve Y5 Start
Flue gas analysis Status Values
Gas steam blower Max 0 or 1 Flame current: uA RPM: Start
Gas steam blower Min 0 or 1 Flame current: uA RPM: Start
Gas hot air blower top Max 0 or 1 Flame current: uA RPM: Start
Gas hot air blower top Min 0 or 1 Flame current: uA RPM: Start
Gas hot air blower bottom Max 0 or 1 Flame current: uA RPM: Start
Gas hot air blower bottom Min 0 or 1 Flame current: uA RPM: Start
