V08 en, SCC - 28 -
Door contact
switch (S3)
CM_P - Parts location
Hand shower
roll guide
PCB (A1)
safety thermostat
steam generator (F3)
safety thermostat cabi-
net (F4)
Potentiometer Time
- Core probe
