Rational CombiMaster Plus CMP User Manual

- 85 - V08 en, SCC
CM_P - Function test - F
Motor bottom MIN rpm
oor models only
BUS Set rpm Act. rpm
clockwise
201 / 202 only
Motor bottom MIN rpm
oor models only
BUS Set rpm Act. rpm
anti clockwise
201 / 202 only
Solenoid valve
quenching
X19:(2-4)
actual temp.
B2 quenching
Y2
1 / 0
Solenoid valve
lling
X19:(1-3) Level electrode
S2, 1 / 0
Y1
1 / 0
SC Pump
X18:(1-2) M4
X12:(1-4) S2
Level electrode
S2, 1 / 0
M4
1 / 0
Buzzer X8:(1-2) 1 / 0
All Displays / LED
Relays Ultravent /
extraction hood
X 23: (1-2-3) 1 / 0
Y5 Clima valve
1 / 0
Gas blower Steam MIN
rpm
BUS actual rpm Set CO2
Check CO2
value
Gas blower Steam Start
rpm
BUS actual rpm
Gas blower Steam MAX
rpm
BUS actual rpm Set CO2
Adjust CO2
value with
CO2 screw
Gas blower Hot air top
MIN rpm
table units / oor units
top
BUS actual rpm Set CO2
Check CO2
value
Gas blower Hot air top
Start rpm
table units / oor units
top
BUS actual rpm
Gas blower Hot air top
MAX rpm
table units / oor units
top
BUS actual rpm Set CO2
Adjust CO2
value with
CO2 screw
Gas blower Hot air bottom
MIN rpm
oor units bottom
BUS actual rpm Set CO2
Check CO2
value
Gas blower Hot air bottom
Start rpm
oor units bottom
BUS actual rpm
Gas blower Hot air bot-
tom MAX rpm
oor units bottom
BUS actual rpm Set CO2
Adjust CO2
value with
CO2 screw
Drain valve 90° micro switch 1 / 0
Drain valve 270° micro switch 1 / 0
Cleanjet pump M6 1 / 0
