8.1.3

WalledGarden



ToconfigureWalledGarden,goto:Network>>WalledGarden.



Thisfunctionprovidescertainfreeservicesforuserstoaccessthewebsiteslistedherebeforeloginandauthentication.

Upto20addressesordomainnamesofthewebsitescanbedef inedonthislist.

Userswithoutthenetworkaccessrightcanstillhaveachancetoexperiencetheactualnetworkservicefreeofcharge.

EntertheIPAddressorDomainName(ofthewebsite)onthelistandclickApplytosavethesettings.


