ReadyLinks GL Series User Manual

Label
Description
Console
Console port: A RS-232 connector for connection to a computer
for console control/administration. The RS-232 console port can
be used for accessing the device CLI (command line interface) for
out-of-band management.
MON
Monitor port, 1 x 1GE local system provision/monitoring port
G1/G2
2 x 1GE Ethernet ports for uplink aggregation
XG1/XG2
2 x 10GE SFP Ethernet ports for uplink aggregation
G.hn
G.hn ports for data signl
The following table shows the LED descriptions.
Label
Type
Color
State
Description
PWR A/B
Power status
Yellow
On
The power is on and supplying the
current to the system
Off
The power is off or it is not supplying the
current to the system
SYS
System status
Green
On
System is started
Off
System has not started
G.hn
G.hn link status
Green
On
The corresponding port connection
normal
Off
The link condition is poor or there is no
connection to this port
Yellow
On
The corresponding port connection
abnormal and link quality is poor
Off
The link condition is normal or there is no
connection to this port
XG1/XG2
Ethernet link status
Green
On
The corresponding port connection
normal
Off
there is no connection to this port
G.hn
G.hn port status
Green
On
The corresponding port is selected.
Off
The corresponding port is not selected.
Slot
Slot status
On
The corresponding slot is selected.
Off
The corresponding slot is not selected.
G1/G2/
MON
Ethernet link status
Green
On
Connection Rate 1000Mbps
Off
Connection Rate 10/100 Mbps
