ReadyLinks GL Series User Manual

status
Off
Connection Rate 10/100 Mbps
Yellow
On
The corresponding port connection
normal
Off
There is no connection to this port
Blink
The G1/G2/ MON port is up and this port
is working.
2.1.2 Physical and Environmental
• Dimension: 19-inch rack-mount width, 1.0U height.
• Case: Aluminum, degree of protection IP30
• Weight: 3.2Kg
• Operating temperature: 0℃ ~ 60℃
• Storage temperature: -25℃ ~ 70℃
• Humidity: 10% ~ 90% RH Non-condensing
• Maximum power consumption: ~32W
2.2 GL-8xT (Headend)
GL-8xT is the device of multiplexer system, as shown in the following drawings. It supports 2
x10G SFP ports, 2 x 10/100/1000BT ports, 8 x twisted pair g.hn Ports, one gigabit monitor
port.
2.2.1 Panel
The front panel is shown below:
The following table shows the port descriptions.
