3 Web-based Management
Port Select the port to configure
Egress The desired egress rate limit to be configured. Choose “disabled” to set the
port with no egress rate limit, which means the port will run in full speed for
egress traffic. You can also select a specific egress rate from the drop-down
list for a port.
Ingress The desired ingress rate limit to be configured. Choose “disabled” to set the
port with no ingress rate limit, which means the port will run in full speed for
ingress traffic. You can also select a specific ingress rate from the
drop-down list for a port.
When
completing
the
configuration,
click
<apply>
to take effect. The next page shows a full list of rate limit for each port.
Caution: Egress rate cannot be enabled on the aggregration ports.
3.4.2 Port Configuration
This tab page sets QoS parameters of each port. For a selected port, set the Priority with
DSCP enabled or disabled, the Default Priority can be set from 0 to 7.
Default Priority There is 8 priorities from 0 to 7.
DSCP Enable or disable DSCP
The lower part of QoS Configuration tab page lists the default priority of all ports and the state
of DSCP.
