3 Web-based Management
⚫ The interface to which the device is connected
⚫ The VLAN to which the interface belongs
Unicast MAC address configuration is for the unicast forwarding mode.
On this page, you can add an entry in MAC table.
VID Specifies a VLAN group with which the MAC address corresponds.
Unicast MAC Address Specifies the destination MAC address.
Port Specifies the port of the outbound interface.
Type Choose among Dynamic, Static and Blackhole.
⚫ Static MAC address entry: Also known as permanent MAC address entry. These types of
MAC address entries are added/removed manually and cannot age out by themselves.
Using static MAC address entries can reduce broadcast packets remarkably and are
suitable for networks where network devices seldom change.
⚫ Dynamic MAC address entry: These types of MAC address entries age out after the
configured aging time. They are generated by the MAC address learning mechanism or
are configured manually.
⚫ Blackhole MAC address entry: These types of MAC address entries are configured
manually. A switch discards the packets destined for or originated from the MAC
addresses contained in blackhole MAC address entries.
The lower part lists all existing unicast MAC addresses, as well as the information of each
unicast MAC address. The user can also modify or delete an existing unicast MAC address.
Dynamic MAC addresses will also be shown on the Dynamic MAC Address page.
3.5.2 Multicast Control
3.5.2.1 Static multicast
This page set static multicast forwarding table
