ReadyLinks GL Series User Manual

Yellow
On
The corresponding port connection
normal
Off
There is no connection to this port
Blink
The G1/G2/ MON port is up and this port
is working.
2.2.2 Physical and Environmental
• Dimension: 19-inch rack-mount width, 1.0U height.
• Case: Aluminum, degree of protection IP30
• Weight: 3.2Kg
• Operating temperature: 0℃ ~ 60℃
• Storage temperature: -25℃ ~ 70℃
• Humidity: 10% ~ 90% RH Non-condensing
• Maximum power consumption: ~32W
2.3 GL-8xMTv2 (Headend)
GL-8xMTv2 is the device of multiplexer system, as shown in the following drawings. It
supports 2 x10G SFP ports, 2 x 10/100/1000BT ports, 8 x twisted pair g.hn Ports, one gigabit
monitor port.
2.3.1 Panel
The front panel is shown below:
The following table shows the port descriptions.
Label
Description
