Notes
Calculating the foil length and the offcut measurement
Calculating the forestay length
D
A — E* — T
D =
________ — ________ — ________
D =
________ mm
Calculating the foil length
B = D — F — G — H
B =
________
—
________
—
________
—
________
B =
________ mm
Rod Wire
Type E* G E* G
RF90-2 105 392 92 389
RF90-3 115 445 110 450
RF90-4 347 480 332 495
RF90-5 495 530 455 555
*
H
Adjuster in middle position
Foil
R20 – R40
90
R5 – R7 100
F (top terminal length) and T (toggle length) must be measured.
Calculating the offcut measurement
C = P — B
C =
________
—
________
C =
________ mm
See packing list for furling section length P
