Operation
Adjusting the forestay length (RF90-2, RF90-3)
48
6.4 Adjusting the forestay length (RF90-2, RF90-3)
Risk of adjuster becoming ripped apart
Stop extending the adjuster as soon as the 'STOP' mark becomes visible under the
outer cover.
After carrying out the adjustment tighten the locking screw again.
1. Completely unscrew the locking screw.
2. Rotate the adjuster tube to lengthen or shorten the adjuster.
3. Screw the locking screw back in tightly.
