RECKMANN RF90 - Rf90-4 Ds; Rf90-5 Ds

Technical data
RF90-4 DS
67
12.3 RF90-4 DS
Foil type R5 R6
Forestay
diameter (max.)
Rod -76 -91
Wire [mm] 19 22
Forestay length (max.) [m] 37.2 43.2
Sail area (max.) [m²] 275 320
Hydraulic motor
Operating pressure (max.) [bar] 140
Torque [Nm] 918
Oil flow rate (max.) [l/min] 37
Rotational speed (max.) [rpm] 33
Hydraulic couplings Motor R½ BSP / with ¾-16 fitting with
internal (female) UNF thread
Adjuster
Stroke [mm] 110
Operating pressure (max.) [bar] 140
Maximum allowable load [kg] 20400
Hydraulic connection R⅛ BSP internal (female) thread
Pos: 94 /ZINDEL/Rollref fanlagen/Techni sche Daten RF90-5 DS @ 1\mod_141 6398841475_13349.doc x @ 14030 @ 2 @ 1
12.4 RF90-5 DS
Foil type R6 R7
Forestay
diameter (max.)
Rod -91 -150
Wire [mm] 26 32
Forestay length (max.) [m] 43.5 49.5
Sail area (max.) [m²] 350 500
Hydraulic motor
Operating pressure (max.) [bar] 175
Torque [Nm] 1102
Oil flow rate (max.) [l/min] 40
Rotational speed (max.) [rpm] 44
Hydraulic couplings Motor R½ BSP / ¾-16 fitting with
internal (female) UNF thread
Adjuster
Stroke [mm] 115
Operating pressure (max.) [bar] 140
Maximum allowable load [kg] 34000
Hydraulic connection R⅛ BSP internal (female) thread
