Technical data
RF90-2 DS
66
12 Technical data
Pos: 91 /ZINDEL/Rollref fanlagen/Techni sche Daten RF90-2 DS @ 1\mod_141 6391443697_13349.doc x @ 14027 @ 2 @ 1
12.1 RF90-2 DS
Foil type R20 R30
Forestay
diameter (max.)
Rod -22 -40
Wire [mm] 10 12
Forestay length (max.) [m] 18.7 23.2
Sail area (max.) [m²] 75 130
Hydraulic motor
Operating pressure (max.) [bar] 120 140
Torque [Nm] 128 148
Oil flow rate (max.) [l/min] 10
Rotational speed (max.) [rpm] 60
Hydraulic couplings BSP ¼ internal (female) thread with
quick coupler
Adjuster
Stroke [mm] 52 (wire), 54 (rod)
Maximum allowable load [kg] 6800
Pos: 92 /ZINDEL/Rollref fanlagen/Techni sche Daten RF90-3 DS @ 1\mod_141 6397262087_13349.doc x @ 14028 @ 2 @ 1
12.2 RF90-3 DS
Foil type R40 R5
Forestay
diameter (max.)
Rod -48 -60
Wire [mm] 16 16
Forestay length (max.) [m] 26.4 36.9
Sail area (max.) [m²] 175 230
Hydraulic motor
Operating pressure (max.) [bar] 140
Torque [Nm] 268 448
Oil flow rate (max.) [l/min] 11 17
Rotational speed (max.) [rpm] 32 32
Hydraulic couplings BSP ¼ internal (female) thread with
quick coupler
Adjuster
Stroke [mm] 49 (wire), 51 (rod)
Maximum allowable load [kg] 13600
